Livestock Gates - Sioux Steel 2.0″ Heavy Duty Gate (HiQual) - Sioux Steel

Sioux Steel 2.0″ Heavy Duty Gate (HiQual)

Model # SHQGTHD04
Manufactured by Sioux Steel
$230.49 - $519.54
$230.49
$230.49 - $519.54
$230.49

Authorized Dealer

Iron Herd is an authorized Sioux Steel dealer, ensuring quality and full manufacturer support.

Size: 4' 2" Heavy Duty Gate

Freight Shipping

Our equipment ships via freight, and shipping costs are charged separately after checkout.

Prefer a single transatcion? Call us to place your order by phone.

Contact us anytime for a freight estimate. (302) 272-9814

HiQual 2" gates are high-quality, working gates with lifetime warranties.

Ideal for almost any application the Heavy Duty Line is HiQual's most popular gate. With 2" x 16 gauge steel rated at 58,000 psi, the Heavy Duty Gate is truly stout. The strength is further enhanced by a 1" x 14 3/4" threaded rod hinge that will even go through a railroad tie.

FEATURES

  • Square corners for livestock safety
  • Strong 16 gauge tube ideal for moderate confinement
  • Long 48" chain with security latch
  • Optimum strength with notched vertical bracing
  • Balanced gate with no weak spots

Suggested Applications

  • Most popular all purpose gate
  • Confinement of cows, calves, and yearlings
  • Pastures
  • Driveways
  • Stallions and mares

SPECIFICATIONS

  • Height: 48"
  • Posts: 2" x 16 gauge round, capped with rubber plug
  • Rails: 5 - 2" x 16 gauge round
  • Braces: 1 ½" x 16 gauge round, notched & welded
  • Chain: ¼" x 48" galvanized proof coil with ¼" quick link
  • Hinge: 1" x 14 ¾" adjustable bolt - 16" long with 14" of thread
  • Paint: Baked on powder coat paint
  • Weight (in pounds): 4' - 43, 6' - 57, 8' - 74, 10' - 87, 12' - 100, 14' - 117, 16' - 131, 18' - 144, 20' - 161
  • Steel: High-tensile, 58,000 psi tubular steel
  • LIFETIME WARRANTIES!
Product # Description Weight
SHQGTHD04 4′ 2″ Heavy Duty Gate 43 lbs
SHQGTHD06 6′ 2″ Heavy Duty Gate 57 lbs
SHQGTHD08 8′ 2″ Heavy Duty Gate 74 lbs
SHQGTHD10 10′ 2″ Heavy Duty Gate 87 lbs
SHQGTHD12 12′ 2″ Heavy Duty Gate 100 lbs
SHQGTHD14 14′ 2″ Heavy Duty Gate 117 lbs
SHQGTHD16 16′ 2″ Heavy Duty Gate 131 lbs
SHQGTHD18 18′ 2″ Heavy Duty Gate 144 lbs
SHQGTHD20 20′ 2″ Heavy Duty Gate 161 lbs



SHIPPING & SUPPORT

This product ships directly from Sioux Steel Company U.S. manufacturing facility. Standard lead time is 5–7 business days to ship.

Have questions or need help choosing the right model and accessories?
Contact us at sales@ironherdequipment.com or give us a call (302) 272-9814— our team is here to help.
